12500 3.85V 리튬이온 원통형 배터리

Li-ion Cylindrical Battery Cell Structure Overview

Manufacturers construct the Li-ion cylindrical battery using a tightly wound jelly-roll architecture inside a rigid metal shell. First, they align the cathode, anode, and separator layers into a continuous laminate sheet, and they roll this assembly into a compact cylindrical core. Meanwhile, engineers insert the rolled structure into a precision-machined steel or aluminum casing. After that, they stabilize internal alignment and prepare the cell for subsequent electrolyte processing under controlled environmental conditions.

Material Composition and Electrode System

Producers apply lithium metal oxide compounds onto aluminum foil to form the cathode layer, while they coat graphite-based slurry onto copper foil to build the anode layer. In addition, they introduce a microporous polyethylene–polypropylene separator to maintain ionic conduction and prevent direct electrode contact. Furthermore, they select a lithium salt electrolyte such as LiPF6 dissolved in organic carbonate solvents, and they ensure chemical stability throughout the system. Meanwhile, the cylindrical housing uses high-strength steel or aluminum alloy to maintain structural integrity under pressure conditions.

전극 권선 및 조립 공정

Technicians cut electrodes into precise strips and then feed them into automated winding equipment. Subsequently, they roll the multilayer stack into a uniform cylindrical “jelly-roll” form while controlling tension and alignment. Then, they insert the wound core into the metal can and connect the bottom electrode to the casing base. After that, they install the top cap assembly and weld it using laser or resistance welding techniques. At the same time, they verify internal positioning to avoid deformation during sealing.

Formation Cycling and Industry Standards Compliance

Engineers execute formation cycling to activate electrochemical reactions and stabilize solid electrolyte interphase layers inside the cell. Then, they conduct aging tests under controlled temperature conditions to evaluate voltage consistency and impedance stability. Finally, quality teams perform dimensional inspection, internal resistance measurement, and safety verification. Throughout production, they comply with IEC 62133 and UN38.3 standards, and they validate mechanical strength, electrical reliability, and transport safety requirements for Li-ion cylindrical battery manufacturing.

제품 특징

1. 🛠️ 커스터마이징 가능
   고객 요구에 맞게 맞춤화 가능하다
2. ⚡ 하이파워
   최대 20C 방전 가능 가능
3. ⏱️ 긴 주기 수명
   장기적인 제품 사용 요구를 충족합니다
4. 🛡️ 높은 안전성
   종합 안전 시험 통과
5. 🔋 진정격 용량
   제품 설계 역량에 부합합니다
6. ⚛️ 다중 화학 옵션
   LCO, NCM, NCA 및 LFP 시스템을 다룹니다
7. 🧰 다중 보호 메커니즘
   과충전, 과방전, 과전류 및 단락 방지 기능이 포함된 내장 보호 보드

제품 적용 분야

이 제품은 다양한 휴대용 및 전원형 전자 장치에 적합하며, 일반적인 응용 분야는 다음과 같습니다:

• 개인 관리 및 건강: 전동 칫솔, 미용 기기, 피트니스 트래커, 의료기기

• 스마트 디지털 및 오디오: 헤드폰, 스피커, 네뷸라이저, 장난감, 조명

• 재정 지급 및 사무실: POS 기계, USB 토큰, 휴대용 프린터
