503450 3.7V 리포 에너지 저장 배터리

3.7V LiPo Energy Storage Battery Structural Overview

Engineers construct the 503450 3.7V LiPo energy storage battery using a flat pouch-cell architecture with tightly controlled dimensional tolerances. First, they align the electrode stack in a layered configuration, ensuring consistent spacing across the entire cell surface. Then, technicians position the cathode, separator, and anode in a stable sequence to maintain internal uniformity. Meanwhile, insulation films are inserted along edge regions to reduce stress concentration during sealing. After stacking, the structure proceeds into lamination and pouch forming operations. (Typical 503450 format: approx. 34×50×5 mm class)

Electrode Materials and Internal Composition

Manufacturers build the cathode using lithium metal oxide coated on aluminum foil, while the anode is formed from graphite-based carbon material coated on copper foil. In addition, a microporous polymer separator is placed between electrode layers to enable lithium-ion movement while preventing direct electrical contact. Furthermore, the electrolyte consists of lithium salts dissolved in organic carbonate solvents, and strict moisture control is maintained throughout filling and sealing. Meanwhile, the aluminum-plastic laminated film acts as the external enclosure, replacing rigid casing with a flexible sealed structure.

Manufacturing Process and Electrode Formation

Technicians begin by mixing active materials, conductive additives, and polymer binders into a uniform slurry. Next, automated coating machines apply the slurry onto metal foils with controlled thickness accuracy. After drying, calendaring rollers compress the electrodes to stabilize density and surface uniformity. Subsequently, the electrodes are cut into precise dimensions matching the 503450 geometry and stacked in layered sequences. Meanwhile, alignment systems continuously monitor stacking accuracy before sealing.

형성 시험 및 준수 기준

Engineers conduct initial charge-discharge cycling to activate electrochemical stability and balance internal interfaces. Afterwards, aging tests evaluate voltage consistency and internal resistance drift over time. Finally, sealing inspection, electrical verification, and safety testing are completed. Throughout production, the 3.7V LiPo energy storage battery follows IEC 62133 and UN38.3 standards, ensuring structural reliability, electrical safety, and transportation compliance.

제품 특징

1. 🛠️ Flexible Customization
   Supports adding wires, protection PCBs, terminal connectors, and other customization based on customer requirements
2. ⚡ 하이파워
   최대 20C 방전 가능 가능
3. ⏱️ 긴 주기 수명
   장기적인 제품 사용 요구를 충족합니다
4. 🛡️ 높은 안전성
   종합 안전 시험 통과
5. 🔋 진정격 용량
   제품 설계 역량에 부합합니다
6. ⚛️ 다중 화학 옵션
   LCO, NCM, NCA 및 LFP 시스템을 다룹니다
7. 🧰 다중 보호 메커니즘
   과충전, 과방전, 과전류 및 단락 방지 기능이 포함된 내장 보호 보드

제품 적용 분야

이 제품은 다양한 휴대용 및 전원형 전자 장치에 적합하며, 일반적인 응용 분야는 다음과 같습니다:

• 개인 관리 및 건강: 전동 칫솔, 미용 기기, 피트니스 트래커, 의료기기

• 스마트 디지털 및 오디오: 헤드폰, 스피커, 네뷸라이저, 장난감, 조명

• 재정 지급 및 사무실: POS 기계, USB 토큰, 휴대용 프린터
